Posted on June 25, 2023June 28, 2023 by Armen Mirzayan — Leave a comment

A Preview of the Fastest Way to Design a Large Temporary Prosthesis

DOWNLOAD THE CASE TO DESIGN ALONG

Name: Medit i700
Brand: Medit
SKU: Medit i5700
Price: 18000 USD
Availability: InStock
Rating: 5 (365 reviews)

One of the most challenging designs to do chairside is the design of a multi unit temporary that needs to be printed. This is incredibly time consuming as you spent significant amount of time just marking margins on a dozen units. With this technique pioneered by CAD-Ray you can bypass the margination step and design a large case in about a minute.

Short Version

There are specific rules and steps you need to follow and one mis-step can cost you a lot of time. You must also understand that you need to keep slicing software limitations in mind so you are not frustrated with the results. Here is a summary:

you cannot have any holes or gaps in any model or between two models that you are trying to combine/unite
you must understand the difference between working and non working surfaces and how to manipulate them
in your wax up designs, you must make sure that the wax up model ALWAYS extends past the margins of your preps.

More Detailed Version

join us in one of our seminars to learn how to expedite this process and learn it in detail

Posted on October 18, 2022October 18, 2022 by Armen Mirzayan — Leave a comment

Capturing Dynamic Mandibular Movements with Medit, an Unapologetic Patent Infringing Feature of 3Shape’s Proprietary and Intellectual Property?

The clash of the titans are in full effect. We are not smart enough to understand all the dynamics of patented software and hardware. While we let the manufacturers sort it out, we wanted to demonstrate how the new mandibular jaw movements are captured in Meditlink

Posted on October 16, 2022October 16, 2022 by Armen Mirzayan — Leave a comment

Additional Scans Catalog Box in Medit Software

Many scanners limit the number of scans you can take on a patient. This becomes cumbersome when you want to image pre-existing conditions, tissue scans for implantology, and other advanced needs

With version 3.0 in Meditlink software, launched in October of 2022, you can import or scan multiple models in the same patient chart

Posted on March 4, 2022June 22, 2022 by Armen Mirzayan — Leave a comment

Fast and Easy Full Arch Temporary by Medit Design Software

Medit Compare, now called Medit Design, now has a boolean cut feature that lets you extract a temporary shell model from wax up or mock up model and prep model for easy and quick designs without painful margin marking on multiple units

Posted on November 4, 2021 by Armen Mirzayan — Leave a comment

Submitting Models for Panthera Obstructive Sleep Apnea Device

It is a good idea to attach support pins to your models so labs don’t lose the vertical dimension and the protrusive position you captured

Panthera Obstructive Sleep Apnea Device

How_to_fill_prescription_D-SAD_L-025

prescription_D-SAD_L-022 v2

Changing the rods RA

D-SAD_Detail_L-021

Glossary_D-SAD_L-23

Dentsply PrimeScan Panthera Dental ordering process

How_To_Send_STL_Panthera_VF_EN

PantheraDental-Order-85368

Posted on October 20, 2021October 20, 2021 by Armen Mirzayan — Leave a comment

Anterior Crown Prep and Model Creator with Die

Here is a preview of the new Medit Model Builder with Ditched Dies where you can print the arches with support pins and separate dies

Model Builder with Dies

Download the case and design along: CAD Ray Anterior Crown and Die

Posted on August 23, 2021 by Armen Mirzayan — Leave a comment

Creating Your Own Dental Morphology Library

Medit Orthodontic Simulation application allows you to segment out individual teeth from patient scans into an stl format that you can use as a template for smile design wax-ups. You have to watch the vide for it to make sense

Export individual morphology

Posted on August 19, 2021August 24, 2021 by Armen Mirzayan — Leave a comment

The Digital 3D Shade Guide

3d-shade-guide-instructions

We’ve digitized the Vita 3D shade guide to help with color identification. The same Medit scanner was used to scan the tabs and then this digital file was created. the assumption is that the same camera and light will hit natural dentition and the net effect will be the same. Use at your own risk.

3D Shade Guide

DOWNLOAD THE 3D Shade Guide

i think this can work!

i scanned the vita 3d shade guide with the same light i would use to scan teeth. Start with matching the value, then the hue, and then chroma.

*** correction made

Posted by Armen Mirzayan on Wednesday, August 18, 2021

Posted on August 2, 2021August 3, 2021 by Armen Mirzayan — Leave a comment

Measuring Intra-Oral Scanner Accuracy and How Accurate is the Medit Scanner?

Still not a single article published that says Medit ios is a good scanner ! its just been user driven for 3 years now.

it’s a good thing, because the world just changed. it is irresponsible to extrapolate research done outside the mouth on stone models or impressions into clinical significance with intra-oral scanning. There are parameters that are impossible to quantify like focal distance throughout the scan (unlike desktop scanners with known focal distances), the codes use to do the algorithms, the scan patterns, and also how light is treated by enamel, dentin, and restored materials.

i can’t believe people still use terms like trueness and accuracy when they really don’t even exist when you scan intra-orally. Like analog impressions, it is impossible to judge digital impression accuracy LIVE while it is happening.

Enter Medit! There are a few distinct ways to demonstrate an accurate scan live while it is happening. One way is to import a geometric shape that doesn’t alter its form while models are being rendered. That’s what’s demonstrated here. To my knowledge no one has ever studied this approach because no other camera lets you do this. i did see some publications where the authors attached objects like radiographic markers and after it was processed, they could measure that object and see if it distorted or not, but nothing at this level.

You can download the case and design along

Posted on August 1, 2021August 1, 2021 by Armen Mirzayan — Leave a comment

Medit’s Model Builder and Ortho Simulation Apps and the American Board of Orthodontics Electronic Cast Radiograph Evaluation (CRE)

The following information is from the The American Board of Orthodontics. We preview how the Medit Ortho Simulation and Model Builder can satisfy their criteria

AOB Standards and Medit

ortho simulation wiht model builder

abo-model-analysis-02-23-2021
grading-system-casts-radiographs

Posted on July 29, 2021July 29, 2021 by Armen Mirzayan — Leave a comment

Introducing the Medit Model Builder

Medit has many free applications, including Smile Analysis, Orthodontic Simulation, and now, Medit Model Builder

Adding bases has been a feature for a while but as usual, Medit was quick to respond to its users’ request by expanding the base to including holes for drainage in printing and by allowing us to add support pins to the models. Many people who have printers, whether labs or clinicians, easily lose the proper vertical relationship when they print the models. By adding these pins, it allows you to index the models properly for any finishing work someone may need to do.

Advanced users are unlikely to use this feature for a single unit, but it comes in handy for oral appliances, particularly when they have advanced the jaw to open the airway. Oh, and this app is free and you can use it with models created by any scanner

Medit Model Builder

Posted on July 27, 2021July 27, 2021 by Armen Mirzayan — Leave a comment

Preview of Medit Compare Used in Merging Models, Modifying Them, Inverting Them, and Relating Them to Each Other with Medit Compare

This case shows how to relate models to each and maintain their relationships. It features the power of the Medit Compare app that lets you duplicate models, trim them, modify them to your liking. There are some very useful features in this app that can come in very handy

an important matter to remember is the “direction of travel” which is taking models from the Target folder and moving it to relate it to the Reference folder.

All models placed in each folder will maintain their relationships to each other when traveling to connect with the other models. Inverting models will also come in handy for advanced users. You can see the full video and download the case and design along here

Duplicating Overdentures with Medit Compare

Posted on November 18, 2020November 19, 2020 by CAD-Ray — Leave a comment

A Mix of All of the Medit Features Include Compare, Smile Design, Model Imports, CT scans, Image, Videos, etc…

Compare and Smile Design Features

in this case we import multiple models, videos, CT scans, and Face Scans so that our users can utilize all of these features. Click here to enter the member’s section to download the whole case and design along
